Description
Features
MyRIDE? Suspension System
The suspended operator platform allows up to 9 cm of travel (depending on model) and reduces impacts, bumps and vibrations. Easily and quickly adjust rear shock ride settings to personal ride preferences, without tools!
Exclusive TURBO FORCE? Deck
High-capacity TURBO FORCE decks deliver unsurpassed strength, a superior cut, and increased productivity in extreme mowing conditions. Equipped with a patented adjustable baffle, TURBO FORCE decks can be fine-tuned in order to conquer changing turf conditions.
7-Gauge, High-Strength Steel
The TURBO FORCE deck is constructed of 7-gauge, high-strength steel which is 33% thicker and 32% higher in yield strength than ordinary 10-gauge commercial steel used in 7/10 decks. The combined effect is 75% stronger, so it easily handles the most demanding conditions and resists damage from impacts and abrasion.
A Flat Crisp Cut with Precision Blades
(.250) thick precision blades resist flexing to provide a flat, crisp cut. High-strength, heat-treated alloy steel survives impacts and provides resistance to the rapid wear commonly associated with abrasive conditions. Options include Recycler? and Atomic? mulching blades, medium sail Bahai blades, and low sail sand blades.
Deluxe Handcrafted Seat with Arm Rests
Ultimate padding and back support with a handcrafted seat with arm rests and bullhorn logo.
Rubber Discharge Chute
High performance rubber discharge chute allows for close trimming without damaging chute or landscape structures. Patented design provides exceptional clipping dispersion.
Smarter design in a bull-nose bumper.
7-gauge bull-nose bumper not only protects against frontal impacts, but also contains an integral underskirt to minimize blowout of debris and dust. The bottom, leading edge of the deck is raised 6 mm, allowing grass to stand more upright when entering the cutting chamber, ensuring a level cut. Leaf “plowing” during spring and fall clean-up also is significantly reduced.
Patented Adjustable Baffle
Allows operator to achieve maximum cutting performance by fine-tuning deck to conquer changing conditions, unique job sites or different times of the season. In extreme conditions, the baffle can be opened in order to conserve power and achieve faster mowing speeds. In less demanding conditions, the baffle can be closed to yield micro-sized particles and maximise discharge velocity.
Smooth, Powerful Response
The new unitised pump and wheel motor use proven commercial hydraulic components while eliminating hoses and other potential leak points. You’ll get a smoother, faster response while enjoying an even more reliable machine.
Operator Information Center
The instrument panel includes a digital hour meter, fuel gauge, and voltage meter, as well as diagnostic indicators for the safety interlock system.
Folding Rollover Protection System ROPS
A Rollover Protection System (ROPS), complete with seat belt, comes standard for operator protection in the case of accidental rollovers and tipovers. In situations where sufficient vertical clearance is not available, such as loading on an enclosed trailer, the ROPS can be temporarily unlocked and folded down.
Cast Aluminum Spindle
Cools quickly for enhanced durability and performance.
Specifications
Engine
31 HP* (23.12 kw) Kawasaki? FX 921cc
Fuel Capacity
Petrol 45 litre single-point fill
Adjustable Discharge Baffle
Standard, tools-free
Air Filter
Heavy-Duty Canister Air Cleaner
Blade Tip Speed
18,500+ ft/min (5,640 m/min)
Blade Type
1/4″ (6 mm) thick heat-treated steel
Carrier Frame
7.6 cm x 3.8 cm tubular steel
Caster Tyres
33 cm x 16.5 cm – 15.2 cm flat-free semi-pneumatic
Deck Design
80-Grade 7-Gauge 152 cm (60″) TURBO FORCE? w/bull-nose bumper
Discharge Chute
Rubber
Drive System
Hydraulic unitised pumps and wheel motors
Drive Tyres
61 cm x 30.5 cm – 30.5 cm
Ground Speed
19 km/h forward
Height of Cut
2.5 – 14 cm in 6 mm increments
Hour Meter
Standard
Hydraulic Fluid
Premium synthetic
ROPS
Folding; standard
Comfort Platform
MyRIDE? Suspension System
Platform Travel
9.1 cm
Shocks
1 Center / 2 Rear
ISO Mounts
Qty 4, 2.5″ 3-D isolation mounts
Seat
Handcrafted deluxe suspension seat with arm rests featuring bullhorn accent
Adjustability
5 point adjustment on rear shocks
Spindle Bearings
Greaseless ball bearings
Spindle Housing
22.9 cm diameter cast aluminium
Steering Controls
4 cm dia. levers; adjustable
Warranty
5 years or 1,400 hours
3 years Engine
