Description
Features
Kohler? EFI Engine
Kohler? Closed-Loop EFI engine provides the highest productivity with the lowest operating cost and reduced carbon footprint. It?s the easiest, the most reliable starting engine and backed by Kohler?s unlimited hour three year commercial warranty. The electronic governor system eliminates governor droop and regulates the engine speed at varying loads, which improves fuel efficiency.
Toro Next Gen Horizon? Technology and Electronic Governor (E-Gov)
The Toro? Next Gen Horizon? Technology system is an on-board intelligence platform that enables communication and response between key systems on the mower. It enhances the machines? overall performance in a wide range of mowing conditions, hence increasing fuel efficiency.
The Toro? Horizon? system uses a speed control module and a throttle/rocker switch (Max, Economy and Low modes) to interact with the Kohler? EFI and electronic governor systems to command engine RPM and throttle plate angle according to load.
Exclusive TURBO FORCE? Deck
The rugged TURBO FORCE? deck is constructed of 7-gauge, high-strength steel with bull-nose bumper, which is 33% thicker and 32% higher in yield strength than ordinary 10-gauge commercial steel. The combined effect is 75% stronger, so it easily handles the most demanding conditions and resists damage from impacts and abrasion.
Semi-Pneumatic Flat-Free Caster Tyres
Eliminate time-consuming flats.
Unibody Frame
Lighter and more durable frame. The frame has been positioned lower to the ground, improving centre of gravity, balance and traction in most conditions. As an added perk, it?s made the machine easier to handle.
Twin Unitised Pump and Wheel Motor Transmissions with Cooling Fans
Proven commercial hydraulic components while eliminating hoses and other potential leak points. You?ll get a smoother, faster response while enjoying an even more reliable machine.
Instrument Panel
The easy to see instrument panel includes a digital hour meter, fuel gauge, voltage meter and diagnostics indicators for troubleshooting at a glance.
Operator Comfort and Control
Deluxe suspension seat features thick cushions, large bolsters and 3-D isolator mounts that absorb bumps and vibrations to reduce operator fatigue.
Folding Rollover Protection System
A Rollover Protection System (ROPS), complete with seat belt, comes standard for operator protection in the case of accidental rollovers and tipovers. In situations where sufficient vertical clearance is not available, such as loading on an enclosed trailer, the ROPS can be temporarily unlocked and folded down.
Specifications
Engine
34 hp (25.4 kW) Kohler? Command Pro EFI ECV940, electronic governor and Toro? Next Gen Horizon? Technology 999 cc
Cutting Width
183 cm
Deck Material
TURBO FORCE? 7-gauge high-strength steel with bull-nose front bumper
Deck Type
Side discharge tools-free adjustable baffle
Fuel Capacity
45.42 Litres
Maximum Forward Speed
18.5 km/h
Drive Tyres
24″ x 12″ – 12″
Caster Tyres
13″ x 6.5″ – 6″ flat-free semi pneumatic
Height of Cut
1.0″ – 5.5″
Rubber Discharge Chute
Standard
Spindle Housing
22.9 cm diameter cast Aluminium
Spindle Bearings
Premium greasable tapered rolling bearings
Blades
0.25″ heat-treated steel
Blade Tip Speed
18,500+ ft/min
Carrier Frame Construction
3″ x 1.5″ x 10 gauge
