Description
Features
23HP V-twin vanguard engine
Chain driven over head camshaft engine
High & low ratio gearbox
Limited slip diff lock selected from the dashboard
Shaft driven cutter deck train
Variable speed Hydrostatic transmission complete with charge pump, oil filter & 7 litre tank
A cast iron compact tractor front axle set with planetary hubs
Foot control for forward & reverse movement
Selectable 2WD & 4WD from the dashboard on the run
Drum brakes and park brake
drum brake
Dual range for increased pulling and climbing power
NO DECK BELT! Shaft driven cutting deck. Explore extreme terrain without the fear of breaking a belt
Low centre of gravity for amazing stability on slopes and rough terrain
Easy and safe control layout so anyone can operate
Steering column adjustable for reach, length and angle
Hour meter and grab handles
Easy tool-less blade changing ? unique swinging & opening blade guard
Comfortable ride and easy operation
Low centre of gravity or amazing stability on slopes and rough terrain
Easy tool-less blade changing system with unique swinging & opening blade guard
Specialist Diff lock for traction (works just as well climbing & descending)
Specifications
Engine – 23HP Vanguard V-Twin
Rated Net Output – 23HP@3600rpm
Weight (fuel tank full) – 360 Kg
Gradeability – 25 degrees
Stability Angle – 25 degrees left & right
Max Speed – 13.8 km/h
Fuel Tank – 20 Litres
Min turning radius – 1800mm
Cutting Width – 965 mm
Cutting Height – 0 ? 150 mm (21 heights)
Drive Train – 4 Wheel Drive
