Honda SXS700

Honda SXS700

Like the PRO-FXT petrol model counterpart the six-seater PRO-DXT EPS offers “Diesel economy”, “Durability” and “Comfort and Convenience”. The diesel model was designed primarily for work applications, where their high-torque diesel engine will deliver excellent performance and allow on-site fuel compatibility. With a greater focus on cargo carrying and transportation, the PRO-DXT EPS can be transferred from a three seater features a spacious cargo bed, to a handy six-seater with ample room, making it the workhorse of choice for customers who need to transport staff and/or haul material.

The Mule PRO-DXT’s combination of Diesel economy, durability, comfort and convenience make it the industry’s most dependable outdoor partner. The PRO-DXT features Electric Power Steering, seats up to six adults with a ROPS approved Cab Frame and 3-point seat belts for added peace of mind.

Enquire Now
Category:

Description

ENGINE/DRIVE TRAIN

At the heart of this Australian spec Pioneer 700 is Honda’s proven fuel-Injected 700cc-class liquid-cooled OHV single cylinder four-stroke engine.

Fuel injection means it will always start up, even on cold days or at high altitude and an all-new intake design helps minimise dust ingestion. Automotive-style automatic transmission with hydraulic torque converter, three forward gears and reverse.

In contrast to a belt drive system, the automotive-style Honda Automatic Transmission, with a heavy-duty torque converter and three hydraulic clutches provides positive engine braking. Electric power steering and fully automatic transmission now comes with a manual mode that can be activated via a dash-mounted toggle switch; use the steering-column-mounted paddle shifters to change gears while in manual mode, or to override shift points on the fly while in automatic mode.

CHASSIS/SUSPENSION

The 2017 Pioneer 700-4s rugged and solid construction is supported by long-travel suspension of 200mm in front and 230mm in the rear which provides a plush ride with class-leading stability.

In addition to a fully independent rear suspension, the rear shocks feature preload adjustability to handle the Pioneer’s generous load capabilities, Honda’s Pioneer is ready for the toughest work.

OTHER FEATURES

Seat Belt Interlock feature for improved safety which prompts drivers to wear their seatbelt. This feature will limit the speed of the vehicle when the seatbelt is not engaged reducing the likelihood of an injury.

Features several well thought out details like a standard water-resistant glovebox door, easy to read dash and patented QuickFlip seating design which offers the versatility and adjustability of two-, three-, or four-person seating configurations. The seating arrangement can be quickly and easily changed thanks to a folding, stowaway rear-seat design; provides full bed space and tilt function while in the two-person configuration.

Ready to tackle the toughest Australian terrain, the compact dimensions of Honda’s new Pioneer offers high level of manoeuvrability and the impressive turning radius will get the Pioneer out of any tight spot.

Available in Honda’s iconic Patriot Red, the Pioneer has rugged and aggressive styling.

NOTE

Please note overseas models shown, any accessories shown are not standard. FOR DETAILED SAFETY INFORMATION VISIT: http://hondaworkrange.com.au/safety

Honda Pioneer is recommended for drivers 16 years of age and older, and tall enough to wear the seat belt properly and reach all the controls. The passenger should also be tall enough for the seat belt to fit properly and brace themselves, if needed, by placing both feet firmly on the floor while grasping the hand hold.

SPECIFICATIONS

ENGINE

ENGINE TYPE: 675cc liquid-cooled OHV single-cylinder four-stroke

BORE AND STROKE: 102.0 x 82.6mm

COMPRESSION RATIO: 9.2:1

INDUCTION: Fuel Injection (PGM-FI), 40mm throttle body

IGNITION: Full-transistorized with electronic advance

STARTER: Electric

CLUTCH: Automatic

TRANSMISSION: Automotive-style with hydraulic torque converter, three forward gears and Reverse. Selectable automatic and manual modes.

DRIVELINE: Direct front and rear driveshafts

DRIVE MODE: 2WD, 4WD and 4WD with differential lock

FRAME

DIMENSIONS(LXWXH): 2915 x 1524 x 1990mm

WHEELBASE: 1950mm

GROUND CLEARANCE: 267mm

FUEL CAPACITY: 31 litres, including 4.5 litres reserve

KERB WEIGHT: 647kg

PAYLOAD CAPACITY: 454kg

COLOUR: Red

TYRES

FRONT: 25 x 8-12 inch

REAR: 25 x 10-12 inch

SUSPENSION

FRONT: Independent double-wishbone; 200mm travel

REAR: Independent double-wishbone; 230mm travel

BRAKES

FRONT: 200mm hydraulic disc

REAR: 170mm hydraulic disc

FEATURES

POWER STEERING: Standard
