Description
Smart Start®
The engine and starter have been designed so the machine starts quickly with minimum effort. Resistance in the starter cord is reduced by up to 40%.
Auto return stop switch
Stop switch automatically resets to the ON position for trouble-free starting.
Easy starting
Air purge for very easy starting.
Low noise engine
Effective low noise engine design will not disturb you or your neighbours
Specifications
Capacity
Recommended maximum twig diameter: 20 mm
Cutting speed: 4050 cut/min
Engine
Cylinder displacement: 21.7 cm³
Power output: 0.6 kW
Maximum power speed: 7800 rpm
Fuel tank volume: 0.3 l
Fuel consumption: 575 g/kWh
Fuel consumption: 0.33 kg/h
Idling speed: 2800 rpm
Spark plug: NGK CMR6A
Electrode gap: 0.5 mm
Equipment
Knife Length: 45 cm
Teeth opening: 28 mm
Dimensions
Weight: 4.7 kg
Sound and Noise
Sound pressure level at operators ear: 93 dB(A)
Sound power level, guaranteed (LWA): 101 dB(A)
Transmission
Gear ratio: 4.4
Gear ratio: 1
Vibration
Equivalent vibration level (ahv, eq) front handle: 2.9 m/s²
Equivalent vibration level (ahv, eq) rear handle: 4.9 m/s²
