Description
Flip-up tank cap
The flip-up tank cap is easy to open and close when refuelling.
Smart Start®
The engine and starter have been designed so the machine starts quickly with minimum effort. Resistance in the starter cord is reduced by up to 40%.
Quick-release air filter
Facilitates cleaning and replacement of the air filter.
Air Injection
Extends the interval between filter cleaning, improving efficiency and increases engine life.
SPECIFICATIONS
Engine
Cylinder displacement: 40.9 cm³
Power output: 1.8 kW
Maximum power speed: 9000 rpm
#Fuel tank volume: 0.37 l
Idling speed: 2900 rpm
Electrode gap: 0.5 mm
Torque, max: 2.16 Nm
Fuel consumption: 513 g/kWh
Fuel consumption: 0.9 kg/h
Equipment
Bar length: (inch) 16″
Recommended bar length, max: 18 in
Recommended bar length, max: 45 cm
Recommended bar length, min: 13 in
Recommended bar length, min: 33 cm
Chain speed at 133% of maximum engine power speed: 23 m/s
Dimensions
Weight (excl. cutting equipment): 4.4 kg
Lubricant
Oil tank volume: 0.25 l
Oil pump type: Fixed flow
Sound and Noise
Sound power level, guaranteed (LWA): 114 dB(A)
Sound power level, measured: 112 dB(A)
Sound pressure level at operators ear: 102 dB(A)
Vibration
Equivalent vibration level (ahv, eq) front handle: 3.8 m/s²
Equivalent vibration level (ahv, eq) rear handle: 4.2 m/s²
